Ashcroft DG25 Digital Gauges
FEATURES
1% Accuracy (options for accuracy as precise as 0.25%)
Min./Max. function feature records low and high pressure events
Nine engineering units: one field (programmable)
All Stainless steel-laser welded wetted parts
Push-button menu navigation
20 segment bar graph display
5 Digit numeric display
IP67 Enclosure
TYPICAL USES
Hydraulics and pneumatics
Test and measurement
Specialized OEM equipment
Material strength testing
Torque measurement
Weighing
FEATURES
1% Accuracy (options for accuracy as precise as 0.25%)
Min./Max. function feature records low and high pressure events
Nine engineering units: one field (programmable)
All Stainless steel-laser welded wetted parts
Push-button menu navigation
20 segment bar graph display
5 Digit numeric display
IP67 Enclosure
TYPICAL USES
Hydraulics and pneumatics
Test and measurement
Specialized OEM equipment
Material strength testing
Torque measurement
Weighing
FEATURES
1% Accuracy (options for accuracy as precise as 0.25%)
Min./Max. function feature records low and high pressure events
Nine engineering units: one field (programmable)
All Stainless steel-laser welded wetted parts
Push-button menu navigation
20 segment bar graph display
5 Digit numeric display
IP67 Enclosure
TYPICAL USES
Hydraulics and pneumatics
Test and measurement
Specialized OEM equipment
Material strength testing
Torque measurement
Weighing
KEY BENEFITS
• Wide variety of pressure connection thread options
• Easily custom configured to meet unique requirements
• Ingress protection suitable for demanding applications
SPECEFICATIONS
LCD Display:
Five-digit numeric top line, five-character alphanumeric lower line, 20 segment vertical bar graph, four segment battery life indicator, dedicated icons for gauge timer, back light timer, tare, min. and max.
Keypad Functions:
Three key; with multi press functionality
Hard Keys:
On/Off: Power Symbol and Enter Zero
Zero: Tare, and Up Arrow
Menu: Access, Backlight, Down Arrow
Engineering Units:
psi, bar, inHg, cmHg, mmHg, kPa, MPa, kg/cm2, ftH2O, and customer defined unit
Approvals:
CE, UL 61010-1, CUL
